| Performances | Settling Time | 10min |
| Attitude | 0.01 deg, 1σ | |
| Heading accuracy | 0.05° , 1σ autonomous; 0.02 °, with GPS aiding | |
| Heave | 5cm or 5% | |
| Measuring Ranges | Rotation rate | ±400deg/s |
| Acceleration | ±20g | |
| Operating Environment | Operating Temperature | -40℃~+70℃ |
| Storage Temperature | -55℃~+70℃ | |
| Vibration | 0.04g2/hz @ 20~2000hz | |
| Shock | 30g @ 6ms, keep accuracy; 50g @ 11ms, no damage | |
| Electrical Characteristics | Power supply | 18~36VDC |
| Consumption | ≤15W | |
| Physical Characteristics | Size (W x D x H) | 171×308×172 mm |
| Weight | ≤6.8kg | |
| Water proof | IP 66 | |
| Interfaces | RS 232/RS 422 port | 2 inputs / 4 outputs |
| Ethernet port | 1 input | |
| CAN port | 2 outputs | |
| Data formats | NMEA 0183, ASCII, BINARY | |
| Reliability | MTBF | 80,000 hrs |
| Service | Warranty | Three years |
We are a leading manufacturer specializing in cooled and uncooled infrared thermal imaging cameras and modules, surface or underwater fiber optic gyrocompasses, inertial navigation systems, and fiber optic gyroscopes.
Our mission is to create more sustainable and efficient solutions by enhancing human perception through best-in-class intelligent imaging technology. Our professional teams focus on navigation systems, thermal imaging cameras, and sensor development.
With high-tech production lines, we provide fiber optic gyro compasses that offer low cost, reliable quality, and perfect performance for maritime and drone applications. We have achieved convincing experience in many major projects with strong technical strength and a global market reputation.
