X-ray Baggage Scanner Dual View & Dual Energy Fdt-Se6040d for Sport Exhibition Halls

1 / 1

X-ray Baggage Scanner Dual View & Dual Energy Fdt-Se6040d for Sport Exhibition Halls

Customization:	Available
After-sales Service:	12 Months
Warranty:	12 Months

Send Inquiry

Product Description

Basic Specifications

Model NO.

FDT-SE6040D

Portable

Non Portable

Form

Flatbed

Application

Security Check, Industrial

Type

Industrial High-definition X-ray Detector

Certification

CE, ISO, FCC

Alarm Form

Display Alarm

Appearance

Vertical

Product Type

Conveyor

Package

Wooden Box

Specification

2440*1450*1580

HS Code

9022191010

Product Overview

X-ray Baggage Scanner with Dual View & Dual Energy

Model: FDT-SE6040D

X-ray baggage scanners operate based on the x-ray penetration principle. Widely used in national security, which covers national research institutions, detection centers, courts, prisons, procuratorates, Army, airports, subway and railway stations, docks, schools, embassies, tourist attraction, logistics, big events etc.

Technical Specifications

General Specifications

Dimensions 1911(L) × 1245mm (W) × 1370mm (H)	Tunnel Size 605mm (W) × 405mm (H)
Conveyor Speed 0.20 m/s ±0.02m/s	Max. Load 200 kg
Operating Temp/Humidity -10 ºC ~ + 45 ºC / 10% ~ 95%	Power Consumption 1 kVA

Basic Performance

Penetration 43mm Steel Plate	Wire Resolution ≤40AWG
Spatial Resolution Horizontal: Ф1.0mm / Vertical: Ф1.0mm	X-ray Leakage <0.1µGy/h

X-ray Generator

Generation Direction: From bottom & from one side
Tube Voltage: 100~160kV Adjustable
Tube Current: 0.4~1.2 mA Adjustable
Cooling/Duty Cycle: Sealed oil / 100%
Generation Angle: 80°

System Configuration & Features

Advanced Configuration

International brand electrical components
Industrial PLC circuit control
Capacitance integral analog conversion
Industrial computer for stable operation
Ergonomic reading system
Radiation protection system

Image Processing Functions

Color / Black & White Imaging
Organic / Inorganic Discrimination
Super & Edge Enhancement
Grayscale Scanning & Restoration
High/Low Energy Penetration
Image Storage (>100,000 pictures)
High Density Alarm
Drug and Explosive Powder Detection

Frequently Asked Questions

1. Are you a manufacturer of security detection systems? Yes, we are a professional manufacturer. Our focus is on providing strong, durable, and high-quality systems alongside consistent technical service.

2. What are your main product series? We offer 11 security series including X-Ray Baggage Scanners, Body Scanners, Walk Through Metal Detectors, Under Vehicle Surveillance, and Explosive/Narcotics Detectors.

3. What is the warranty policy? We provide a one-year free warranty for non-human caused failures and lifetime technical support. Paid warranty extensions are also available.

4. Do you provide installation and training services? Yes, we offer installation services, online one-on-one training for partners and end-users, and comprehensive debugging and maintenance support.

5. How long is the delivery lead time? For items in stock, the lead time is 3-5 days. For production orders without stock, it typically takes 10-20 days.

6. How is quality control managed? Every production process is strictly controlled in accordance with ISO9001, CE, and FCC certification standards.
